Installation Instructions 49-1000
5
Remove the stock bump stops and replace with extended bumps. 17.
Install the track bar drop bracket. Mock up the bracket and mark the
hole. Remove the bracket. And center punch the mark. 18.
Remove the factory lower arms and replace with ReadyLIFT®
Off Road Arm. The adjustable end is to be mounted at Axle 13.
Remove the factory upper arm and replace with the ReadyLIFT®
Off Road Arm. Note: For diesel vehicles you may need to remove the
exhaust for clearance to remove passenger upper arm.
14.
Diesel Models Only: Unbolt the exhaust at the muffler. Remove the exhaust clamp from
header, unbolt the bracket from the transmission. Unhook the exhaust sensor and lower the
pipe to make clearance to remove the upper arm and frame side bolt.
15.
Once arms are installed, re-install the exhaust and tighten all corre-
sponding mounting points and hardware. 16.
Drill the marked hole to a 1/2 inch diameter. Re-install the track bar bracket
with provided hardware and spacers, placing the spacer in between the
frame and bracket. 19. Install the new pitman arm. 20.
