Chapter 1 19
LCD 17”
Card Reader
Item Specification
Vendor/model name CMO N173O6-L02
Screen Diagonal (mm) 439.4
Display Area (mm) 382.08 x 214.92
Display resolution (pixels) 1600 x 900
Pixel Pitch 0.2388
Display Mode Normal
Typical White Luminance (cd/m
2
)
(also called Brightness)
220
Contrast Ratio 600:1
Response Time (Optical Rise
Time/Fall Time) msec 8
Typical Power Consumption
(watt) 7
Weight 580 max.
Physical Size (mm) 398.1 x 232.8 x 5.5
Electrical Interface LVDS
Support Color 262K
Viewing Angle (up/down/right/
left) 20/45/45/45
Temperature Range (°C)
Operating
Storage (shipping)
0 to +50
-20 to +60
Item Specification
Part Name RealTek RT5159
Package 5-in-1 card reader
General Features • PCI-E interface
• Push-push type
• Dummy card
