15
No. Code Description
1 CN4 Top: PS/2 mouse port
Bottom: PS/2 keyboard port
2 USB3 USB ports
3 COMA1 Serial A port
4 LPT1 Parallel/printer port
5 VGA1 VGA/monitor port
6 LAN Gigabit LAN ports (RJ-45)
7 ATX2 Power supply connector
8 CPU2 CPU 2 socket
9 CPU FAN2 CPU fan 2 connector
10 ATX1 Power supply connector
11 PWR FAN1 Power fan 1 connector
12 DIMM 1-4 DIMM slots for CPU 1
13 DIMM 5-8 DIMM slots for CPU 2
14 CPU1 CPU 1 socket
15 CPU FAN1 CPU fan 1 connector
16 AMD 8131 chipset
17 AMD 8111 chipset
18 SCSI_CON1 SCSI module connector
19 CLR_CMOS1 Clear CMOS jumper
20 F_PANEL1 Front panel LED connectors
21 USB1 Front USB connectors
