Describes index of the font being used. The fonts have to be loaded on the flash
memory of the TouchKey before they can be used. The a user defined. The list below
shows the default font found in each MCI TouchKey:
0 Verdana 8 pt fat
1 Verdana 8 pt
2 Verdana 20 pt fat
3 Verdana 12 pt fat
4 MS Sans Serif 18 pt fat
5 MS Sans Serif 12 pt
6 Verdana 10 pt fat
7 Verdana 14 pt fat
8 Verdana 16 pt fat
Example: 0
This defines the of the touch field. Multiple buttons (keys) with different text
descriptions have to have specific indexes in order to be used.
The value range is: 0-63
A value of 255 automatically takes the next free index.
Example: 1
Sends key codes when pressed (True) or released (false).
Example: true
The name of the layout that is started when the button is pressed.
Example: drinks
This section defines virtual key codes and scan codes. A 0 is always required at the
end of each block. Please see the description of "Scan codes" and "virtual keys" at
the end of this document.
Virtual key code of the key. The decimal number is used for entering the value.
Example: 49
Indicates if a make- (true) or break- (false) gets sent.
Example: true
