PS
S
ERIES HARDWARE SETUP PROCEDURE
Horizontal
• Install the “U” bracket as described in preceding section
• Connect the “U” bracket to the connector plate by using the srews provided with the VNI-WS kit;
• Secure
the
screws;
• Suspend and secure the cabinet to the wall suspension;
• Adjust
horizontal
angle
WALL SUSPENSION PROCEDURE FOR HORIZONTAL INSTALLATION
