OPERATION
25 | PreSonus 2007
Bass Guitar
COMPRESSOR SETTINGS
THRESH RATIO GAIN SOFT BYPASS ATTACK RELEASE
-15 dB 7:1 +4 dB In Out Mid-Fast Mid-Slow
EQ SETTINGS
LOW MID HIGH
EQ>COMP PEAK GAIN FREQ Q GAIN FREQ PEAK GAIN FREQ
Out In +6 dB 85 Hz Mid-Narrow -3 dB 2.2 kHz Out 0 dB n/a
Keyboards
COMPRESSOR SETTINGS
THRESH RATIO GAIN SOFT BYPASS ATTACK RELEASE
-22 dB 4:1 +4 dB Out Out Mid-Fast Mid-Slow
EQ SETTINGS
LOW MID HIGH
EQ>COMP PEAK GAIN FREQ Q GAIN FREQ PEAK GAIN FREQ
Out In -3 dB 20 Hz Mid-Narrow +4 dB 2.2 kHz Out +3 dB 6.5 kHz
Kick Drum
COMPRESSOR SETTINGS
THRESH RATIO GAIN SOFT BYPASS ATTACK RELEASE
-18 dB 5:1 +2 dB Out Out Mid-Fast Mid-Fast
EQ SETTINGS
LOW MID HIGH
EQ>COMP PEAK GAIN FREQ Q GAIN FREQ PEAK GAIN FREQ
In Out +8 dB 60 Hz Narrow -8 dB 400 Hz Out +6 dB 2.5 kHz
Snare
COMPRESSOR SETTINGS
THRESH RATIO GAIN SOFT BYPASS ATTACK RELEASE
-22 dB 6:1 +4 dB In Out Mid Mid
EQ SETTINGS
LOW MID HIGH
EQ>COMP PEAK GAIN FREQ Q GAIN FREQ PEAK GAIN FREQ
Out Out 0 dB n/a Mid +2 dB 1kHz Out -2 dB 20 kHz
