AXIS 221/223M Installation Guide Page 3
ENGLISH ENGLISH ENGL
ISH
AXIS 221/223M
Installation Guide
This installation guide provides instructions for installing the AXIS 221/223M on your
network. For all other aspects of using the product, please see the User’s Manual, available
on the CD included in this package, or from www.axis.com/techsup
Installation steps
1. Check the package contents against the list below.
2. Hardware overview. See page 4.
3. Connect the cables. See page 5.
4. Set an IP address. See page 6.
5. Set the password. See page 9.
Package contents
Important!
Item Models/variants/notes
Network camera AXIS 221 Network Camera
AXIS 223M Network Camera
CS lens adaptor ring (AXIS 223M only)
PS-K indoor power supply country specific
Terminal block connector 10-pin connector block for connecting external devices to the I/O
terminal connector
3-pin connector block for connecting power to the 3-pin power
connector
CD AXIS Network Video Product CD, including product documentation,
installation tools and other software
Printed Materials AXIS 221/223M Installation Guide (this document)
Axis Warranty Document
To use the AXIS 221/223M outdoors it must be installed in a protective housing. For
more information on protective housings and other accessories, please visit
www.axis.com
Important!
This product must be used in
compliance with local laws
and regulations.
