Pump connections, Fig. 1, Fig. 2 fig. 3 – Stuart Turner Boostamatic4S/L7-4S User Manual
Page 5
- 5 -
Cont ...
PUMP CONNECTIONS
Model
Inlet
(Pump)
Outlet
Fig. No.
4000
G 1 Female
G 1 Female
1
6000
G 1 Female
G 1 Female
1
K7-2
G 1 Female
G 1 Female
3
L5-4S
G 1¼ Female
G 1 Female
2
L7-4S
G 1¼ Female
G 1 Female
2
PUMPS
Fig. 1
Reed Switch
Assembly
Reed Switch
Assembly
Reed Switch
Assembly
Inlet
Inlet
Inlet
Outlet
Outlet
Outlet
Fig. 2
Fig. 3
