0
F
R12
R134a
30
42
40
32
44
42
34
46
44
36
48
46
38
50
49
40
52
51
42
54
54
44
57
56
46
59
59
48
61
61
50
64
64
52
66
67
54
69
70
56
72
72
58
74
76
60
77
78
62
80
82
64
83
85
66
85
88
68
88
92
70
92
95
72
95
97
74
98
104
76
102
107
78
105
110
80
108
114
82
112
118
84
115
123
86
118
127
88
123
130
90
127
135
92
130
140
94
135
145
96
138
148
98
143
153
100
147
157
102
150
163
104
155
167
106
160
173
108
165
180
110
168
185
112
173
190
114
178
195
116
183
200
118
188
207
120
193
213
Purge Chart
PURGE AIR - DRAIN OIL
IMPORTANT: Air must be purged and oil drained after each
recycle procedure. Failure to do so will cause excess air to
be introduced into the A/C during charge and the AC2880
will fill with excess oil causing serious operational
problems.
During automatic operation only, the AC2880 will stop after
the deep vacuum procedure and display PURGE AIR AND
DRAIN OIL as a reminder.
1. Turn on power.
2. Press the purge switch for five seconds.
3. Slowly open oil drain valve and drain oil into measuring cup.
Leave valve open and go to next step.
4. Measure the room temperature.
5. Find the corresponding pressure for this temperature on the
appropriate R12 or R134a purge chart.
6. Compare this pressure from the chart with that indicated on
the purge gauge on the side of the AC2880. If the gauge
shows a higher pressure, press the purge switch until the
pressure drops to the pressure shown in the chart.
7. Close oil drain valve.
8. Press the purge switch for five seconds to complete the
purge procedure.
