Yokogawa JUXTA MS5 - Manual

User’s
Manual
Network Solutions Business Division
2-9-32, Naka-cho Musashino-shi, Tokyo 180-8750 Japan
Phone: +81-422-52-7179
Facsimile: +81-422-52-6793
1
Please read through this User’s Manual before use for correct handling.
Please keep this User’s Manual for future reference.
Model MS5
Potentiometer Converter
(Free Range Type)
CAUTIONARY NOTES FOR SAFE USE OF THE PRODUCT
This User’s Manual should be carefully read before installing and oper-
ating the product. The following symbol is used on the product and in
this manual to ensure safe use.
This symbol is displayed on the product when it is
necessary to refer to the User’s Manual for information on
personnel and instrument safety. This symbol is displayed
in the User’s Manual to indicate precautions for avoiding
danger to the operator, such as an electric shock.
The following symbols are used only in this manual.
IMPORTANT
Indicates that operating the hardware or software in a
particular manner may cause damage or result in a system
failure.
NOTE
Draws attention to essential information for understanding
the operations and/or functions of the product.
CHECKING PRODUCT SPECIFICATIONS AND PACKAGED ITEMS
(1) Checking the Model and Product Specifications
Check that the model and specifications indicated on the nameplate
attached to the main unit are as ordered.
(2) Packaged Items
Check that the package contains the following items:
● MS5: 1
● Spacer (for DIN rail mounting): 1
● Range label: 1
● User’s Manual (this manual: IM 77J04S05-01E): 1
GENERAL
The MS5 is a plug-in type potentiometer converter that is used in com-
bination with an instrument to transmit information for displacement of
valve etc. by resistance change of potentiometer. It converts the resis-
tance changes into isolated DC current or DC voltage signals.
IM 77J04S05-01E
1st Edition Jul. 2005 (YK)
MODEL AND SUFFIX CODES
MS5 -01 - 00 /
Model
Output
1: 1 output
Power supply
1: 15-40V DC (Operating range: 12 to 48 V)
6: 100-240 V AC/DC (Operating range: 85 to 264 V)
Input signal
1: Potentiometer resistance
(Total resistance 100
Ω to 10 k Ω )
Z: (Custom order)
Customized potentiometer resistance
Output signal
A: 0 to 20 mA DC Span is 5 mA or more
B: 0 to 5 mA DC Span is 1 mA or more
1: − 10 to + 10 V DC Span is 0.1 V or more
2: − 100 to + 100 mV DC Span is 10 mV or more
Z: (Custom order)
Customized current signals or voltage signals
Optional specification
/SN: Without socket
IM 77J04S05-01E
