Yokogawa DA100 User Manual
User’s manual, Da100 data acquisition unit, Notice of alterations

Notice of Alterations
Yokogawa Electric Corporation
User’s
Manual
Please note the following(underlined) alterations to the IMDA100-01E.
Page 3 “Main Unit DA100”
Model
Suffix Code
Description
··············
······························································
Type
-1························ Stand-alone model
-2························ Expandable model
-B························ DU100-11 (Input module) and DT300-21 (Communication module) are attached
-C························ DU100-21 (Input module) and DT300-21 (Communication module) are attached
-D························ DU100-31 (Input module) and DT300-21 (Communication module) are attached
-E························ DU100-11 (Input module) and DT300-41 (Communication module) are attached
-F························ DU100-21 (Input module) and DT300-41 (Communication module) are attached
-G························ DU100-31 (Input module) and DT300-41 (Communication module) are attached
-Q························ DU100-11 (Input module) and DT300-31 (Communication module)* are attached
-R························ DU100-21 (Input module) and DT300-31 (Communication module)* are attached
-T························ DU100-31 (Input module) and DT300-31 (Communication module)* are attached
* With Modbus communication function
··············
······························································
Power Cord
D········· 3-pin inlet w/UL, CSA cable (Part No. A1074WD)
F········· 3-pin inlet w/VDE cable (Part No. A1004WD)
R········· 3-pin inlet w/AS cable (Part No. A1024WD)
S········· 3-pin inlet w/BS cable (Part No. A1023WD)
H········· 3-pin inlet w/GB cable (complies with the CCC)(Part No. A1064WD)
W········· No power cord, Screw terminal
Y········· No power cord, 2-pin round-type connector (only when power supply code is -2)
Page 3 “Subunit DS400/DS600”
Model
Suffix Code
Description
··············
······························································
Power Cord
D········· 3-pin inlet w/UL, CSA cable
F········· 3-pin inlet w/VDE cable
R········· 3-pin inlet w/AS cable
S········· 3-pin inlet w/BS cable
H········· 3-pin inlet w/GB cable (complies with the CCC)
W········· No power cord, Screw terminal
Y········· No power cord, 2-pin round-type connector (only when power supply code is -2)
Page 5 “Standard Accessories”
DA100-B, -C, -D, -E, -F, -G, -Q, -R, and -T are appended to the following accessories in addition to the
above-mentioned standard accessories by the customer of purchase.
Main Unit Type
Name
Model
Q'ty
DA100-B
10-channel universal input module
DU100-11
1
RS-232-C module
DT300-21
1
RS-232-C cable
1
DA100-C
20-channel universal input module
DU100-21
1
RS-232-C module
DT300-21
1
RS-232-C cable
1
DA100-D
30-channel universal input module
DU100-31
1
RS-232-C module
DT300-21
1
RS-232-C cable
1
DA100-E
10-channel universal input module
DU100-31
1
Ethernet module
DT300-41
1
DA100
Data Acquisition Unit
IM DA100-01E-88 1/6
for IM DA100-01E 8th Edition
