4. DIMENSIONS
Figure 9: Dimensions of FU20F Sensor
Figure 10: Dimensions of quick-removal adapters /NSS, /NTI, /BSS, /BTI
Figure 11: Dimensions of F*40 adapter /FPS
3/4” TAPERED THREAD 3/4” TAPERED THREAD
22.5 (0.89”)
19.6 (0.78”)
19.6 (0.78”)
51.0 (2.1”)
150.0 (5.9”)
10.0 (0.39”)
-NPT
/NSS, /NTI, /BSS, /BTI
-FSM
65.5 (2.58”)
21
(0.83”)
Ш 22.0 (0.86”)
Ш 26.0 (1.02”)
1” NPT or ISO 7/1-R1
Ш 35.5 (1.4”)
Ш 39.0 (1.54”)
99.0
(3.9”)
25.0
(1”)
1” NPT or
ISO 7/1-R1
/NSS, /NTI, /BSS, /BTI
/FPS
Dimensions in mm (inches)
IM 12B6J3-04E-E
17
