8
IM12B6J1-40E-E
Figure 6 Figure 7
15°
Minimum
Position
.
Ш 36
Ш 54
32
23
1
20
PG13.5
10
5
ш30
ш36
ш30
3/4” NPT
1/4” NPT
1/4” NPT
30 (1.18”)
100 (3.94”)
Ø30
PG 13,5
60
153 (6.0”)
PG13,5 adapter
K1523JB
PG13,5 adapter
K1523JA
Conductivity
Flow Fitting
FF40
SC4A
option
/FF
K1523JA K1598AC
Flow fitting FF40 with K1523JA
Adapter to fit sensors with a PG13,5
process connection in FF40/FS40 and
FD40 fittings. Material: Polypropylene. Flow fitting option /FF K1598AC
(incl. 3.1 certificate) with Adapter
K1523JB to fit sensors with PG13,5
process connection.
Position
