14
ETH Lit green when connected to an Ethernet device.
Blinking when data is transmitted or received via Ethernet port.
BUTTON MEANING
WPS Push this button to trigger Wi-Fi Protected Setup function.
SYNC Used to establish a LAN network with other power line devices.
Push this button for 1~3 second(s) and release it to set device enter the
power line Sync state.
Press the Sync Button of device for more than 10 seconds to make sure
that it is detached completely from any possible network group.
RESET Press this button 3 seconds to reset device to factory default settings.
Due to the incompatibility of HomePlug AV 200 with HomePlug
1.0 devices, the presence of the HomePlug 1.0 devices within
the powerline network will thus reduce the performance of
your powerline network.
For a device which already belongs to a network group is to
join with a different network group, that device has to be
ungrouped from its current attached group first. Press the Sync
Button of device for more than 10 seconds to make sure that
it is detached completely from any possible network group.
5. Cabling
Plug NetPower 303 WN into the wall outlet/socket.
With the power source on, once the device is connected, the Power, LAN and WLAN
port LEDs will light up indicating a normal status.
If the LAN Port’s Link indicator does not light up then check the RJ-45 cable if it is
firmly feed to the RJ45 port, while the LAN is link up to the Switch/Hub, the LAN
port’s LED will light up.
The control LEDs of the device are clearly visible and the status of the network link
can be seen instantly.
