25

6.6 Bleeding Air from the Hydraulic System

First, make sure the oil level in the reservoir is correct. The oil should be level with the bottom threads
of the oil level port. Use fully synthetic oil: Mobil1 15W-50. With the bypass valves open and the engine
running, slowly move the control levers back and forth five or six times. Now close the bypass valves
and with the engine running, slowly move the control levers back and forth five or six times. It may be
necessary to repeat the above steps until all the air is purged and the rear wheels are turning at normal
speed. After purging is complete, adjust the oil level in the reservoir if necessary.

6.7 Hydro Oil Tank Check/Fill

Checking oil

Ensure mower is on a level surface.

Lift hinged pad and remove hex socket plug from oil level

port on the back of the tank.

Hydro oil should be at the bottom of the threads.

Filling oil

Lift hinged pad and remove hex socket plug.

Using a funnel, fill tank through oil level port until oil

reaches bottom threads of the port.

6.8 Lubrication

The Wright Stander is made with sealed bearings, oil based bushings and with limited grease fittings
therefore only the front caster wheels and caster pivots need to be
greased. (See maintenance chart for service intervals)

Grease with No. 2 general purpose lithium base or molybdenum base

grease.

Set parking brake, stop the engine and remove the key.

Clean grease fittings with a rag.

Connect grease gun to fitting and pump until grease begins to ooze

out from the bearings.

Wipe off excess grease.

Do not use spray lube of any kind on choke and/or throttle cables.

6.9 Battery Service

The battery is 12 volts and is a maintenance free battery.
Charge the battery only if it will not start the mower properly.
Remove the battery from the mower before charging. Follow
the instructions of the battery charger for proper and safe
charging of the battery.




Fill Here
