24

6.3.2 Replacing the Drive Belt

Stop the engine, remove the key and wait for

all moving parts to stop.

Remove the deck cover and remove the blade

belt. (Refer to replacing the cutter deck belt
section)

Raise and secure mower

Remove the belt by using a ½” ratchet and

extension to relieve the belt tension.



6.4 How to Move the Mower if the Engine Won’t Start

Rotate both of the hydro bypass valve levers on the side of each hydraulic
pump about ½ turn counterclockwise. It is important not to over tighten
these levers. Damage may occur to the pump if this valve is over
tightened.


6.5 Hydraulic System

Whenever servicing the hydraulic system, it is of the utmost importance to keep any dirt or debris from
getting into the system. Clean off all parts before disassembly and assembly. When any of the hydraulic
parts are disconnected or removed or when the oil is changed, air must be bled from the system. If air is
entrained in the system, loss of power, excessive heat, and damage to the hydraulic pumps may occur.

Low Pressure Feed

Low Pressure Return

High Pressure Hose



















WARNING
