9a 9b 9c – Pfister 0X6-440R User Manual
Page 8
8
Install Hose Guide & Spray Hose
Instale la guía de la manguera y la manguera del aerosol
Installer le guide de tuyau et tuyau de jet
Adjustable Wrenchs
Llaves ajustable
Clés réglable
Save Components.
Reserve los componentes.
Conservez
les composants.
¡
Disassemble Hose Guide
Desensamble la guía de la manguera
Démontez le guide de tuyau
IMPORTANT: DO NOT OVERTIGHTEN.
IMPORTANTE: NO APRIETE EXCESIVAMENTE.
IMPORTANT: NE PAS TROP SERRER.
¡
9
L
F
M
K
9A
9B
9C
1 3/8” - 2 3/4”
(35 - 70 mm)
F1
F1
K
F2
F3
F4
F5
L
M
L
F2
F3
F4
F5
