Install anchor instale la ancla installer l'ancre – Pfister 0X6-440R User Manual
Page 13
13
Hex Wrenche
Llave hexagonal
Clé hexagonale
Position Anchor (G) with Set Screw facing tub.
Coloque la ancla (G) con el tornillo de ajuste orientado hacia la tina.
Placez la pièce d'ancrage (G) avec la vis de pression orientée vers la
baignoire.
Install Anchor
Instale la ancla
Installer l'ancre
15
Proceed with trim installation.
Continúe con la instalación de la moldura.
Procédez à l'installation de la garniture.
1 3/8” - 2 3/4”
(35 - 70 mm)
G
G
