Status, Config, Util, and Test Menu Options
These menu items can access the same modified menus that you can ac-
cess through the front panel. For detailed information on the available
menu options, refer to the following sections:
• Status Menu in Chapter 4.
• Configuration Menu in Chapter 5.
• Utility Menu in Chapter 6.
• Test Menu in Chapter 7.
DS0 Maps Configuration Menu
The Telnet/Terminal version of the DS0 maps configuration menu takes
advantage of the 24-line VT 100 display. Upon entering this menu, the
current Temp Map displays followed by nine selections that you can use
for configuring and reviewing map information.
Figure 8-2. DS0 Temp Map
• Use the up and down arrows or number keys to move the cursor
from one selection to another.
• Use the Enter key to perform the action displayed in the LCD to the
right of the cursor.
TEMP MAP
DS0 # PORT DS0 # PORT
1 IDLE 13 IDLE
2 IDLE 14 IDLE
3 IDLE 15 IDLE
4 IDLE 16 IDLE
5 IDLE 17 IDLE
6 IDLE 18 IDLE
7 IDLE 19 IDLE
8 IDLE 20 IDLE
9 IDLE 21 IDLE
10 IDLE 22 IDLE
11 IDLE 23 IDLE
12 IDLE 24 IDLE
1) COPY MAP A TO TEMP MAP
2) COPY MAP B TO TEMP MAP
3) CREATE TEMP MAP
4) REVIEW MAP A
5) REVIEW MAP B
6) REVIEW TEMP MAP
7) EDIT TEMP MAP
8) APPLY TEMP MAP TO MAP A
9) APPLY TEMP MAP TO MAP B
