Chapter 3. Operation
3-6 TSU 600 User Manual 61202076L1-1
Selecting and Activating a Menu Item
The front panel menu tree is shown below.
Figure 3-2. Example of Basic Front Panel Menu Travel
Step Action
1 Choose a menu item by placing the cursor on the desired
menu item by either:
1. pressing the number corresponding to the menu item or,
2. highlighting it with the up and down arrows.
2 To activate the Alarm List option from the Status Menu
do the following:
1. Activate the Status Menu using the arrow keys or by
pressing 1 . The cursor will flash on the number next to
the activated selection.
2. Press Enter.
3. Use the arrow keys to view submenu items.
4. Choose an item on the submenu such as ACTIVE
ALARMS .
5. Select the submenu with the arrow keys or by pressing
3 .
6. Press Enter.
7. View the Alarm List using the arrow keys.
1) NI PERF RPTS
2) NI ERRORS
3) ACTIVE ALARMS
(ALARM LIST)
4)VIEW HISTORY END OF LIST
1)STATUS 5) PORT STATUS
6) REMOTE PORT
7) CLEAR PORT ALM
8) ENET STATUS
9) PS STATUS
