Appendix C. Network Pinouts
C-4
TSU 600 User Manual
61202076L1-1
10BaseT (600e only)
10BaseT is used to connect the TSU 600e to the Local Area Network. See
Table C-4.
10BaseT Connections
The required wiring connections are:
Connector Type
(USOC)
RJ-45
Part Number
AMP# 555164-1
Table C-4.
10BaseT Ethernet
Pin
To NIC
1
TX1
2
TX2
3
RX1
6
RX2
