Pfister 016-300K - Manual (Page 4)

E
N
G
L
IS
H
ENGLISH
ENGLISH
13
14
15
16
CAUTION: Maintenance
DISASSEMBLY
1. Replacement parts may be available at the store where you purchased
your faucet.
2. When replacement parts are not available, please write or call Price
Pfi ster Consumer Service.
3. Always turn off water and relieve pressure before working on your
faucet.
NOTE: Trim Care
Cleaning Instructions:
For all Handles and decorative fi nishes, use only a soft damp cloth to clean and shine.
Use of polish, detergents, abrasive cleaners, organic solvents or acid may cause damage.
Use of other than a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain Porcelain or other similar substance are not acceptable for
public areas or Commercial use. Installation of Said Trim is at Users Risk!
1–800–PFAUCET (1–800–732–8238)
For Toll-Free Pfaucet information call
1–800–PFAUCET (1–800–732–8238)
or visit www.pricepfi ster.com
• Installation Support
• Care and Warranty Information
13 UNIT START UP
Turn on hot and cold water supplies, and check all connections for leaks.
14 FINAL FLUSHING
For fi nal fl ushing, turn valve on and allow water to run through the Hose (14A) for several
minutes. Allow water to run for several minutes untill all foreign maTter clears the line.
15 HAND SHOWER FUNCTION
To adjust spray, turn switch (15A) to a desired spray pattern.
Center: Pulsating with Full Spray.
Right: Pulsating.
Left: Full
Spray.
16 SHOWER HEAD INSTALLATION
Thread Hand Shower (16A) onto Hose (16B).
Make sure Hand Shower (16A) is securely tightened to Hose(16B).
4
CENTER
14A
16A
15A
RIGHT
LEFT
16B
