Disable Port Switching Keys
To disable the Port Switching Keys ([Scroll Lock] [Scroll Lock] / [Ctrl] [Ctrl]), do the
following:
1. Invoke HSM (see p. 17).
2. Press [X] [Enter].
Note: This procedure is a toggle. To enable the Port Switching keys repeat steps 1
and 2.
Restore Default Settings
To reset the CS-1772 / CS-1774 to its default hotkey settings, do the following:
1. Invoke HSM (see p. 17).
2. Press [R] [Enter].
All hotkey settings return to the factory default settings. A table showing the default
settings is provided in the Appendix, on p. 32.
Invoke Firmware Upgrade Mode
To set the CS-1772 / CS-1774 to Firmware Upgrade Mode, do the following:
1. Invoke HSM (see p. 17).
2. Key in: upgrade
3. Press [Enter].
The front panel port LEDs flash to indicate Firmware Upgrade Mode is in effect.
Note: To exit Firmware Upgrade Mode, you must power off the switch.
2005-03-16
Hotkey Setting Mode
21
