Relay Interface Board Installation Guide
16
TABLE 5. 32 I/O Rack (J4)
Module # Controller Function CLS204-4CLS CLS208-8CLS CLS216-16CLS MLS316-16MLS MLS332-32MLS
0 Dig Out 1 Loop 1 Heat Loop 1 Heat Loop 1 Heat Loop 1 Heat Loop 1 Heat
1 Dig Out 2 Loop 2 Heat Loop 2 Heat Loop 2 Heat Loop 2 Heat Loop 2 Heat
2 Dig Out 3 Loop 3 Heat Loop 3 Heat Loop 3 Heat Loop 3 Heat Loop 3 Heat
3 Dig Out 4 Loop 4 Heat Loop 4 Heat Loop 4 Heat Loop 4 Heat Loop 4 Heat
4 Dig Out 5 Pulse Loop Heat Loop 5 Heat Loop 5 Heat Loop 5 Heat Loop 5 Heat
5 Dig Out 6 Loop 1 Cool Loop 6 Heat Loop 6 Heat Loop 6 Heat Loop 6 Heat
6 Dig Out 7 Loop 2 Cool Loop 7 Heat Loop 7 Heat Loop 7 Heat Loop 7 Heat
7 Dig Out 8 Loop 3 Cool Loop 8 Heat Loop 8 Heat Loop 8 Heat Loop 8 Heat
8 Dig Out 9 Loop 4 Cool Pulse Loop Heat Loop 9 Heat Loop 9 Heat Loop 9 Heat
9 Dig Out 10 Pulse Loop Cool Loop 1 Cool Loop 10 Heat Loop 10 Heat Loop 10 Heat
10 Dig Out 11 Dig Out 11 Loop 2 Cool Loop 11 Heat Loop 11 Heat Loop 11 Heat
11 Dig Out 12 Dig Out 12 Loop 3 Cool Loop 12 Heat Loop 12 Heat Loop 12 Heat
12 Dig Out 13 Dig Out 13 Loop 4 Cool Loop 13 Heat Loop 13 Heat Loop 13 Heat
13 Dig Out 14 Dig Out 14 Loop 5 Cool Loop 14 Heat Loop 14 Heat Loop 14 Heat
14 Dig Out 15 Dig Out 15 Loop 6 Cool Loop 15 Heat Loop 15 Heat Loop 15 Heat
15 Dig Out 16 Dig Out 16 Loop 7 Cool Loop 16 Heat Loop 16 Heat Loop 16 Heat
16 Dig Out 17 Dig Out 17 Loop 8 Cool Pulse Loop Heat Loop 1 Cool Loop 17 Heat/
Loop 1 Cool
