A p p l i c a t i o n 2 6

Wa t l o w M

I N I

C

H E F

2 0 0 0

3

Configuration Mode Quick Reference

These are the functions, parameters and values included in the Configuration Mode for
this application. You must select Application 26 to access them. For directions, see the
Hardware & Software Setup Guide. The Appendix of that guide includes an explanation
of all parameters and values.

F

unction

Parameter

Value

Your Settings

{Etype} Equipment-Type

[appl`] Application Number

1 - 28

26

[a_Loc] Application Number

Yes, No

Security Lock

[setpt] Setpoint

[tr`lo] to [tr`Hi]

[SEtUP] Setup

[`З_П`] Temperature Display Format

°C or °F

[time] Time Display Format

MMM:SS, HH:MM, H:MM:SS

[Chirp] Key Chirp

On, Off

[loc``] Menu Security Lock

Yes, No

[tc```] Thermocouple Type

J, K (shown as [````H]), E

[rtd``] RTD Curve

DIN, JIS

[tconp] WATCURVE Temperature On,

Off

Compensation

[Ofst1] Temperature Offset, Channel 1

-99 to 99°F (-55 to 55°C)

[tr`lo] Temperature Range Low

0ºF (-18º C) for RTD inputs
32ºF (0ºC) for tc inputs to [tr`Hi]

[tr`Hi] Temperature Range High

[tr`lo] to 1200ºF (649ºC0

[ready] Preheat Ready Feature

Yes, No

[rband] Ready Band

1 to 1200°F (649°C)

[Cloc`] Real Time Clock Display

Yes, No

[al``1] Alarms for channel 1

None, Dev, Proc, Both

[aL`P1] Absolute Process Alarm 1

100 to 1200°F (38 to 649°C)

[aLdL1] Low Deviation Alarm 1

-999 to 0°F (-555 to 0°C)

[aLdH1] High Deviation Alarm 1

0 to 999°F (0 to 555°C)

[[`diag] WatHelp

Used for equipment troubleshooting and testing. Not used when programming. See the Hardware

Diagnostics

& Software Setup Guide.
