-10-
5) Attach the power terminal cover to the power supply terminal
block, and secure it in place with the power terminal cover attach-
ment screws. The proper torque is 0.5 to 0.6 N•m.
When attaching the power terminal cover, be careful
not to pinch the power supply cable.
6) Connect all the cables according to the specifications of the Unit.
When attaching a keyboard or a similar device to the PS-600G,
remove the sticker from the side face of the Rear Cover.
Power Terminal Cover
Power Terminal Cover
Attachment Screws (black)
Sticker
Attaching the Desktop Stand
1) As shown below, use the display attachment screws to attach the
Desktop Stand to the Unit's Rear Cover. The proper torque is 0.6
to 0.8 N•m.
Desktop Stand
Display Attachment Screws
