Electron Beam Systems
Product Description
BroadBeam electron beam systems are designed for
industrial applications. Each BroadBeam is configured
to match the customer’s needs for product width,
dosage level, accelerating voltage and product
handling. BroadBeams are self shielded. All of the
shielding interlock devices and sensors required for safe
operation are included with the machine.
The EP Series has been successfully addressing
applications from 150 to 300 kV for 30 years. The
newly introduced LE Series leverages the proven
BroadBeam design for applications requiring 70 to 175
kV. Our patented Integrated Shield Roll design delivers
optimal web handling without sacrificing easy access.
Specification Range
BroadBeam Delivers:
•
Dependable Operation - less down time and more profit
• Industry’s Best Uniformity - tighter process control
•
Engineering Strength - designs to precisely meet your needs
Web/Product Width 12 to 130 inches
Accelerating Voltage 70 kV to 300 kV
Throughput Up to 50,000 kGy - FPM
Dose Uniformity Better than +/- 8.0%
Line Speeds Up to 2000 FPM (600 MPM)
Beam Orientation Horizontal, Vertical, or Angled
