Pilot Line Specifications
· 100 kV to 300 kV
· 26” (660 mm) Wide Web
· 24” (610 mm) Max. Diameter
· 3.0 PLI Web Tension
· 900 ft/min Max Line Speed
· Operate with or without chill roll
· Nitrogen Inerting
· Coat Weights from 1.2 to 4.0 lbs. /
3000 ft 2
Electron Beam Pilot Line
PCT’s Pilot Line includes:
Unwind Stand
Secondary Unwind for Laminating
Offset / Direct Gravure Coater (8” rolls)
Rewind Stand with Edge Guiding
Capability of Running Rigid Substrates
Adaptability to Custom Configurations
Are you looking for “green” production methods? Is high speed, energy efficient, no VOC
curing technology of interest? PCT can help you discover how electron beam technology can
improve your process.
PCT Engineered Systems offers the use of our
Electron Beam Pilot Line. The pilot line, located at
our facility in Davenport, Iowa, allows our
customers to run proof of concept tests, product
development trials and limited production runs in
order to see how electron beam technology can
improve their processes. Unique testing
requirements can also be met by tapping into the
innovation of PCT’s engineering team.
Discover the power of electrons!
For further information, current pricing, or to schedule your trials, please contact us today.
