FC5150
RF Silicon IC tuner
For Digital Cable TV standards
G
G
Preliminary
3 / 30
April. 2013
Future
Communications
Integrated circuit Inc.
Introduction
The FCI FC5150 is a highly integrated low-power silicon tuner IC targeting at cable broadcasting
standard with digital RF technology. Broadband input filtering and channel filtering have been
completely integrated on-chip. This integration enables a very compact design requiring a small
footprint, low cost, and low power consumption. A signal at the 75ohm RF input is filtered and
converted to a programmable Low-IF output of 4 to 5MHz output. Automatic gain control, LO
generation, and channel selectivity functions are completely integrated on the chip, which simplifies
board-level design. All functions of the IC can be controlled via I2C interface. FC5150 can be
available in a 4 X 4 mm
2
32-pins QFN package.
FEATURES
Highly integrated digital device for world-wide cable broadcasting standard
Tuning range from 45MHz to 862MHz
Low power consumption
Integrated channel filtering requiring, no external SAW filters
Support internal auto digital calibration, no manual alignment, no external inductor for
tracking filters
On-chip 107dB gain control range with single AGC
Programmable IF; 4 to 5MHz
Programmable channel bandwidths up to 8MHz
I2C-compatible digital control interface
