Product datasheet 4/5 Preliminary 15/Oct/2012
FC8400
Advanced Terrestrial Digital Multimedia Broadcast
RF tuner & Demodulator

Electrical Characteristics
 Embeded LDO for Power
 Supply voltages : 1.2V for core and 1.8/2.5/3.3V for I/O
 Low Power consumption : 34 mW
 Various power consumption management devices for this application
 Zero IF support
 Support various external clock 16.384/19.2/24.576/27.12/38.4MHz
 Band Frequency
 Band-III : 170 ~ 240 MHz
 Sensitivity : -103.0 dBm
 Noise Figure : 2.7 dB
 Adjacent Channel Sensitivity : 50 dB
 Far Off Sensitivity : 55 dB

Physical Characteristics
 49 Pin BGA package with 4x4 mm 2
 48 Pin QFN package with 6x6 mm 2
