ⓒ Copyright 2012 FCI (All Rights Reserved)
Product datasheet 3/5 Preliminary 15/Oct/2012
FC8400
Advanced Terrestrial Digital Multimedia Broadcast
RF tuner & Demodulator
1.2. Features

Highly integrated digital device for DAB receiver (Eureka 147)

Korea DAB/DMB/AT-DMB (TTAS.KO -07.0024 and TTAS.KO-07.0026 and TTAK.KO-07-0070)
standard compliant

DAB OFDM channel demodulator and decoder
 Fully integrated, supports all DAB functions and modes (I, II, III and IV)
 Automatic Mode Detection (AMD)
 Full data rate of 1.8Mbit can be decoded for HP path
 Automatic frame and time synchronization and fast channel re-acquisition
 Digital AGC with a wide gain control range
 Demodulation and decoding of up to 64 sub-channels (UEP/EEP)
 TII decoder
 Automatic multiplex re-configuration

AT-DMB OFDM channel demodulator and decoder
 Fully integrated, supports all AT-DMB function and modes (B, Q mode)
 Fully integrated, supports all AT-DMB alpha (1.5, 2.0, 2.5, 3.0)
 Fully integrated, supports all AT-DMB code rate (1/2, 1/3, 3/4, 2/5)

Integrated high-density SRAM supporting time and frequency de-interleaving
 Simple memory concept. Do not require external memory for DAB operation

Interfaces
 Parallel Host Interface
 3-bit control pins, 2-bit address bus and 8-bit data bus
 3-bit control pins, 8-bit data bus, it is compatible with Qualcomm QSC series modem chip.
 Serial Host Interface
 SPI : up to external Crystal clock
 I2C : up to 1.0MHz for control
 Serial TSIF : up to external Crystal clock for data
 Support Host Interface for max. 7 services
 HP/LP FIC
 Max. 2 service for video stream
 Max. 3 service for audio or data stream
 MPEG-2 Serial-TS output
 Various TS clock : external Crystal clock / 7 ~ external Crystal clock
 Be able to decode 2 video data with RS encoded stream
