Floppy disk controller, Ieee 1394 controller, Serial ata controller – Abit Intel Pentium 4 System Board Socket 775 AW8 User Manual
Page 48: Network 1/ network 2 controller, Power management setup, Power management setup -20, 6. power management setup
3-20
Chapter 3
Floppy Disk Controller
This option enables or disables the floppy disk controller.
# Onboard PCI Device:
Click
IEEE 1394 Controller:
This option enables or disables the IEEE 1394 controller.
Serial ATA Controller
This option enables or disables the Serial ATA controller.
! SATA RAID ROM
This item allows you to use the boot ROM of on-chip Serial ATA RAID to boot-up system.
Network 1/ Network 2 Controller:
This option enables or disables the LAN controller.
! Invoke Boot Agent:
This item allows you to use the boot ROM (instead of a disk drive) to boot-up the system and access the
local area network directly.
3-6. Power Management Setup
AW8 Series
