P S L S E R I E S 3 0 . 5 M M P U S H B U T T O N E N C L O S U R E S
N E M A 1 2 O P E R AT O R I N T E R FA C E
H24
F E AT U R E S - S P E C I F I C AT I O N S
Applications
Designed to hold all standard brands of
pushbuttons, switches and pilot lights.
Provides protection from dust, dirt, oil
and water. This “Slimline” model is
designed for conditions where enclo-
sures must fit within very limited areas.
Construction
• Fabricated from 14 gauge steel
• Continuously welded seams ground
smooth
Industry Standards
UL 508, Types 12 & 13
CSA Certified, Types 12 & 13
NEMA/EEMAC Type 12 & 13
JIC EL-1-71
U L F i l e s E 6 4 7 9 1
C S A F i l e L L 6 6 0 7 8
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
CATALOG BODY/DOOR ENCLOSURE SIZE MOUNTING OVERALL
NUMBER STEEL GAUGE H X W X D C X E L X M
F I
P S L 1 1 4 / 1 4
4 . 0 0 x 2 . 5 0 x 2 . 5 0 1 . 6 3 x 4 . 5 0 5 . 0 0 x 2 . 8 1 2 . 2 5 2 . 0 9
( 1 0 2 x 6 4 x 6 4 ) ( 4 1 x 1 1 4 ) ( 1 2 7 x 7 1 ) ( 5 7 ) ( 5 3 )
P S L 2 1 4 / 1 4
6 . 2 5 x 2 . 5 0 x 2 . 5 0 1 . 6 3 x 6 . 7 5 7 . 2 5 x 2 . 8 1 2 . 2 5 2 . 0 9
( 1 5 9 x 6 4 x 6 4 ) ( 4 1 x 1 7 1 ) ( 1 8 4 x 7 1 ) ( 5 7 ) ( 5 3 )
P S L 3 1 4 / 1 4
8 . 5 0 x 2 . 5 0 x 2 . 5 0 1 . 6 3 x 9 . 0 0 9 . 5 0 x 2 . 8 1 2 . 2 5 2 . 0 9
( 2 1 6 x 6 4 x 6 4 ) ( 4 1 x 2 2 9 ) ( 2 4 1 x 7 1 ) ( 5 7 ) ( 5 3 )
P S L 4 1 4 / 1 4
1 0 . 7 5 x 2 . 5 0 x 2 . 5 0 1 . 6 3 x 1 1 . 2 5 1 1 . 7 5 x 2 . 8 1 2 . 2 5 2 . 0 9
( 2 7 3 x 6 4 x 6 4 ) ( 4 1 x 2 8 6 ) ( 2 9 8 x 7 1 ) ( 5 7 ) ( 5 3 )
P S L S E R I E S O P E R AT O R I N T E R FA C E 3 0 . 5 M M P U S H B U T T O N E N C L O S U R E S
PSL4
• Closed cell oil resistant neoprene
gasket
• External mounting plates, top and
bottom of enclosure
• Captivated cover screws thread
into sealed wells
• Standard 4-way pushbutton holes
accept all brands of oil-tight push-
buttons, switches and pilot lights
• Grounding provisions provided
Finish
• ANSI-61 gray polyester powder
inside and out over phosphatized
surfaces
Accessories
• See pages J1-J22
