W C 1 4 S E R I E S C O N S O L E S
N E M A 1 2 O P E R AT O R I N T E R FA C E
H10
F E AT U R E S - S P E C I F I C AT I O N S
Applications
Designed to hold electrical and electronic
controls and instruments. Pushbuttons,
pilot lights, meters, switches etc., can
be mounted on the instrument panel.
Interior components are motorized on
stationary sub panels, swing-out sub
panels or relay rack angles (panels
are optional). Heavy duty construction
provides protection from dirt, dust,
oil and water. Numerous accessories
and variable combinations make
these consoles most versatile.
Construction —Body
• Bodies and doors fabricated from
14 gauge steel
• Seams are continuously welded and
ground smooth, less knockouts or holes
• 3-point keylocking handle is provided
on front, main door
• Double overlapping doors are provided
on two door consoles
• Main hinged doors are flush
Industry Standards
UL 508, Types 12 & 13
CSA Certified, Type 12 & 13
NEMA/EEMAC Types 12 & 13
U L F i l e s E 6 4 7 9 1
C S A F i l e L L 6 6 0 7 8
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
• Grounding provisions provided
• One or two large sloping control
panels are hinged on bottom
• Control panels have captivated
screws which thread into sealed wells
• Door stops provided to hold control
panel open
• Two print pockets are included
• Closed cell neoprene gasket is provided
• Horizontal channels are welded to
sides of console to support optional
panels, swing-out panels and rack
mounting angles
• Half, full, and swing panels are
optional
Construction —Top
• Fabricated from 14 gauge steel
• Top unit is 12.50" deep to accom-
modate most instruments
• Seams are continuously welded and
ground smooth, less knockouts or holes
CATALOG NUMBER
CONSOLE
CATALOG NUMBER
CATALOG NUMBER
CONSOLE ONLY
WIDTH
CONSOLE
WRITING
VARIOUS PANEL*
PANEL SIZES
CASTER
CLAMPING
RACK
TOP
DESK
H X W
KIT
NUTS
ANGLES
W C 1 4 B ( S i n g l e d o o r )
2 4 . 0 0 " ( 6 1 0 )
W C 1 4 T
W C 1 4 W
W C 1 4 P 1 ( S w i n g p a n e l )
2 2 . 0 0 x 1 8 . 1 3 ( 5 5 9 x 4 6 1 )
W C 1 2 C
WA P S 1 4 2 0 C N
W C 1 4 R
—
—
—
—
W C 1 4 P 2 ( H a l f p a n e l )
2 2 . 0 0 x 1 7 . 0 0 ( 5 5 9 x 4 3 2 )
—
—
—
—
—
—
—
W C 1 4 P 3 ( F u l l p a n e l )
4 2 . 2 5 x 1 7 . 0 0 ( 1 0 7 3 x 4 3 2 )
—
WA P S 3 8 1 6 C N
—
W C 1 4 3 6 B ( S i n g l e d o o r ) 3 6 . 0 0 " ( 9 1 4 )
W C 1 4 3 6 T
W C 1 4 3 6 W
W C 1 4 3 6 P 1 (Swing panel)
2 2 . 0 0 x 3 0 . 1 3 ( 5 5 9 x 7 6 5 )
W C 1 2 C
WA P S 1 4 2 0 C N
—
—
—
—
—
W C 1 4 3 6 P 2 ( H a l f p a n e l )
2 2 . 0 0 x 2 9 . 0 0 ( 5 5 9 x 7 3 7 )
—
—
—
—
—
—
—
W C 1 4 3 6 P 3 ( F u l l p a n e l )
4 2 . 2 5 x 2 9 . 0 0 ( 1 0 7 3 x 7 3 7 )
—
WA P S 3 8 1 6 C N
—
WC1448BD (Double door) 4 8 . 0 0 " ( 1 2 1 9 )
W C 1 4 4 8 T
W C 1 4 4 8 W
W C 1 4 4 8 P 2 ( H a l f p a n e l )
2 2 . 0 0 x 4 1 . 0 0 ( 5 5 9 x 1 0 4 1 )
W C 1 2 C
WA P S 1 4 2 0 C N
—
—
—
—
—
W C 1 4 4 8 P 3 ( F u l l p a n e l )
4 2 . 2 5 x 4 1 . 0 0 ( 1 0 7 3 x 1 0 4 1 )
—
WA P S 3 8 1 6 C N
—
WC1460BD (Double door) 6 0 . 0 0 " ( 1 5 2 4 )
W C 1 4 6 0 T
W C 1 4 6 0 W
W C 1 4 6 0 P 2 ( H a l f p a n e l )
2 2 . 0 0 x 5 3 . 0 0 ( 5 5 9 x 1 3 4 6 )
WC12C
WA P S 1 4 2 0 C N
—
—
—
—
—
W C 1 4 6 0 P 3 ( F u l l p a n e l )
4 2 . 2 5 x 5 3 . 0 0 ( 1 0 7 3 x 1 3 4 6 )
—
WA P S 3 8 1 6 C N
—
W C 1 4 S E R I E S O P E R AT O R I N T E R FA C E C O N S O L E S
*Full, Half, and Swing panels must be ordered separately.
• Instrument and access panels have
captivated screws which thread
into sealed wells
• 4 holes are provided in bottom of
top for mounting to body
• Instrument and access panels are
removable
• Closed cell neoprene gasket
Construction —Writing Desk
• Fabricated from 14 gauge steel
• Seams are continuously welded
and ground smooth
• Desks are removable and attach
easily to console front
Finish
• ANSI 61 gray polyester powder
inside and out over phosphatized
surfaces
• Optional panels are white polyester
powder over phosphatized surfaces
Accessories
• See pages J1-J22
WC14B
