C C O L & B A S E S E R I E S P E D E S TA L S
N E M A 1 2 O P E R AT O R I N T E R FA C E
H14
F E AT U R E S - S P E C I F I C AT I O N S
Applications
Designed to permit floor mounting of
many types of enclosures and boxes.
Four column and two base sizes are
available. Columns can be mounted
on either base. Wiring connections
can be made through the base, through
the vertical column, or directly to the
enclosure. Columns have flanges at
each end and a gasketed access
plate. Screws, oil-resistant gaskets,
and box connector fitting are fur-
nished with each column for joining
and enclosure to the top of the col-
umn. A cutout must be made in the
enclosure if the wires are to come
through the column.
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
NOTE: The user would normally remove the mounting feet from the enclosure if the enclosure is mounted on a pedestal.
Hubbell Wiegmann can supply enclosures without mounting feet/plates and with cutouts as a special. Consult factory for information.
CATALOG NUMBER
BODY/DOOR
SIZE
DESCRIPTION
GRAY
STAINLESS STEEL
STEEL GAUGE
C
D
F
H
M
N
P
WA 4 4 C C O L
WA 4 4 C C O L S S
1 4
4 . 0 0 x 4 . 0 0
S t r a i g h t p e d e s t a l c o l u m n
—
3 . 7 5
2 . 7 5
—
7 . 2 5
6 . 0 0
—
( 1 0 2 x 1 0 2 )
( 9 5 )
( 7 0 )
( 1 8 4 )
( 1 5 2 )
WA 6 6 C C O L
WA 6 6 C C O L S S
1 4
6 . 0 0 x 6 . 0 0
S t r a i g h t p e d e s t a l c o l u m n
—
5 . 7 5
4 . 7 5
—
8 . 0 0
6 . 7 5
—
( 1 5 2 x 1 5 2 )
( 1 4 6 )
( 1 2 1 )
( 2 0 3 )
( 1 7 1 )
WA 4 4 P B C O L
WA 4 4 P B C O L S S
1 4
4 . 0 0 x 4 . 0 0
A n g l e d p e d e s t a l c o l u m n
—
3 . 7 5
2 . 7 5
—
7 . 2 5
6 . 0 0
—
( 1 0 2 x 1 0 2 )
( 9 5 )
( 7 0 )
( 1 8 4 )
( 1 5 2 )
WA 6 6 P B C O L
WA 6 6 P B C O S S
1 4
6 . 0 0 x 6 . 0 0
A n g l e d p e d e s t a l c o l u m n
—
5 . 7 5
4 . 7 5
—
8 . 0 0
6 . 7 5
—
( 1 5 2 x 1 5 2 )
( 1 4 6 )
( 1 2 1 )
( 2 0 3 )
( 1 7 1 )
WA 1 8 S B A S E
WA 1 8 S B A S E S S
1 0
1 8 . 0 0 x 1 8 . 0 0
P e d e s t a l b a s e
1 8 . 0 6
—
—
1 . 1 3
—
—
0 . 4 7
( 4 5 7 x 4 5 7 )
( 4 5 9 )
( 2 9 )
( 1 2 )
WA 2 4 S B A S E
WA 2 4 S B A S E S S
7
2 4 . 0 0 x 2 4 . 0 0
P e d e s t a l b a s e
2 3 . 8 8
—
—
1 . 3 1
—
—
0 . 7 8
( 6 1 0 x 6 1 0 )
( 6 0 6 )
( 3 3 )
( 2 0 )
O P E R AT O R I N T E R FA C E P E D E S TA L S A N D B A S E S
Construction—Column
• Columns fabricated from 14 gauge
steel with 10 gauge flanges
• Gasket, screws and box connective
fittings are furnished for mounting
consolet
• Columns feature gasketed access
plate
• Stainless steel columns fabricated
from 304 stainless steel
Construction—Base
• 18" bases are fabricated from
10 gauge steel
• 24" bases are fabricated from
7 gauge steel
• Both bases have added reinforcing,
leveling screws and holes for securing
to floor
• Stainless steel bases fabricated
from 304 stainless steel
Finish
• ANSI-61 gray polyester powder
inside and out over phosphatized
surfaces
• Stainless steel product – standard
grain finish
WA44CCOL
WITH OPTIONAL BASE SHOWN
WA44BPCOL
WITH OPTIONAL BASE SHOWN
Industry Standards
Type 12 & 13
U L F i l e s E 6 4 7 9 1
C S A F i l e L L 6 6 0 7 8
