D15
N 4 1 2 - 3 P T C U LT I M AT E S E R I E S E N C L O S U R E S
N E M A 4 S I N G L E D O O R W A L L M O U N T
www.hubbell-wiegmann.com
Data Subject To Change Without Notice
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
N 4 1 2 - 3 P T C U LT I M A T E S E R I E S E N C L O S U R E S N E M A 4 S I N G L E D O O R W A L L - M O U N T C O N T ’ D .
C ATA L O G
N U M B E R BODY/DOOR
STEEL GAUGE E N C L O S U R E S I Z E
H X W X D B A C K PA N E L
S I Z E A & B
N4123020083PTC
N4123024083PTC
N4123030083PTC
N4123624083PTC
N4123630083PTC
N4123636083PTC
N4122020123PTC
N4122420123PTC
N4122424123PTC
N4123024123PTC
N4123030123PTC
N4123624123PTC
N4123630123PTC
N4123636123PTC
N4124024123PTC
N4124236123PTC
N4124824123PTC
N4124836123PTC
N4126036123PTC
N4122424163PTC
N4123630163PTC
N4124836163PTC
N4122424203PTC
N4123024203PTC
N4123630203PTC
NP3020C
NP3024C
NP3030C
NP3624C
NP3630C
NP3636C
NP2020C
NP2420C
NP2424C
NP3024C
NP3030C
NP3624C
NP3630C
NP3636C
NP4024C
NP4236C
NP4824C
NP4836C
NP6036C
NP2424C
NP3630C
NP4836C
NP2424C
NP3024C
NP3630C
NP3020CG
NP3024CG
NP3030CG
NP3624CG
NP3630CG
NP3636CG
NP2020CG
NP2420CG
NP2424CG
NP3024CG
NP3030CG
NP3624CG
NP3630CG
NP3636CG
NP4024CG
NP4236CG
NP4824CG
NP4836CG
NP6036CG
NP2424CG
NP3630CG
NP4836CG
NP2424CG
NP3024CG
NP3630CG
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
14/14
28.2x18.2 (716x464)
28.2x22.2 (716x564)
28.2x28.2 (716x716)
34.2x22.2 (869x564)
34.2x28.2 (869x716)
34.2x34.2 (869x869)
18.2x18.2 (462x462)
22.2x18.2 (564x462)
22.2x22.2 (564x564)
28.2x22.2 (716x564)
28.2x28.2 (716x716)
34.2x22.2 (869x564)
34.2x28.2 (869x716)
34.2x34.2 (869x869)
38.2x22.2 (970x564)
40.2x34.2 (1021x869)
46.2x22.2 (1173x564)
46.2x34.2 (1173x869)
58.2x34.2 (1478x869)
22.2x22.2 (564x564)
34.2x28.2 (869x716)
46.2x34.2 (1173x869)
22.2x22.2 (564x564)
28.2x22.2 (716x564)
34.2x28.2 (869x716)
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
30.00x20.00x8.00 (762x508x203)
30.00x24.00x8.00 (762x610x203)
30.00x30.00x8.00 (762x762x203)
36.00x24.00x8.00 (914x610x203)
36.00x30.00x8.00 (914x508x305)
36.00x36.00x8.00 (914x914x203)
20.00x20.00x12.00 (508x508x305)
24.00x20.00x12.00 (610x508x305)
24.00x24.00x12.00 (610x610x305)
30.00x24.00x12.00 (762x610x305)
30.00x30.00x12.00 (762x762x305)
36.00x24.00x12.00 (914x610x305)
36.00x30.00x12.00 (914x762x305)
36.00x36.00x12.00 (914x914x305)
40.00x24.00x12.00 (1016x610x305)
42.00x36.00x12.00 (1067x914x305)
48.00x24.00x12.00 (1219x610x305)
48.00x36.00x12.00 (1219x914x305)
60.00x36.00x12.00 (1524x914x305)
24.00x24.00x16.00 (610x610x406)
36.00x30.00x16.00 (914x762x406)
48.00x36.00x16.00 (1219x914x406)
24.00x24.00x20.00 (610x610x508)
30.00x24.00x20.00 (762x610x508)
36.00x30.00x20.00 (914x762x508)
DOOR & BOX
STIFFENERS BACK PANEL CATALOG NUMBER*
WHITE “G”
*Back panels must be ordered separately.
A
A
SECTION A-A
W
H
2.25
A
B
0.90
TYP.
0.90
TYP.
0.75
TYP.
0.75
TYP.
0.52
TYP. 0.52
TYP.
5/16-18
COLLAR STUD
H/2
FRONT VIEW
RIGHT VIEW
Ø0.44 TYP.
MOUNTING
PROVISION
D 0.79
3-POINT
HANDLE
PANEL
(Order Separately)
SEE DETAIL A
1.50
0.75
1.41
Ø0.41
OPTIONAL MOUNTING
FOOT
ALTERNATE POSITION
ENCLOSURE
DETAIL A
(OPTIONAL MOUNTING FOOT)
Notes:
1. Large Print Pocket (8 X 10) is
furnished if H=20.00" or more
and W=20.00" or more
Otherwise, small (6 X 6) print
pocket is provided.
2. Two Hinges provided when
H<36.00".
Three Hinges provided when
H=36.00" or greater.
Four Hinges provided when
H=48.00" or greater.
