Versa-Matic 2 Bolted Metallic Ball Valve Pumps (RE2) - Manual (Page 14)

re2mdlAsm-rev0314
www
.
versamatic
.
com
3: EXP
VIEW
11
• Model RE2 Metallic Bolted
Composite Repair Parts drawing - aluminum
Bolted Assembly
Diaphragm Plates — Rubber 65 ft-lbs (88 N-m)
Diaphragm Plates — PTFE 65 ft-lbs (88 N-m)
Air Valve Cap Screws 25 in-lbs (2.8 N-m)
Torque Settings
56
65
55
45
46
58
64
61
54
47
60
51
62
62
63
58
60
RE2 MB PG-11
64
65
Detail: Sensor
METAL SEAT OPTION
59
58
52
General Model Specific
