Series L 5000 Cord Reels
Page 8 www.reelcraft.com
Item
#
Description
#
Req.
L 5550
123 3B
L 5550 123 7
L 5550
123 7B
L 5550
123 7D
L 5550 123 X L 5550 124 X L 5750 103 4 L 5750 103 X
1 Inlet Cord Assembly 1 602002 600564 602002 261165 262307 262328 None None
2 Connector, 90° Cord 1 S261140 S261140 S261140 S261140
262293
262294
262293
262294
S158-3
262293
262294
4 Screw, Set Pin 1 300006 300006 300006 300006 300006 300006 300006 300006
5 Lock Nut 10-32 20 S300011 S300011 S300011 S300011 S300011 S300011 S300011 S300011
6 Snap Ring 1 300031 300031 300031 300031 300031 300031 300031 (x2) 300031 (x2)
7 Spring Case Stud 1 S261360 S261360 S261360 S261360 S261360 S261360 S261360 S261360
8 Screw 10-32 x 1/2 2 300002 300002 300002 300002 300002 300002 300002 300002
9 Guide Arm and Roller 1 S500107 S500107 S500107 S500107 S500107 S500107 S500107 S500107
10 Hose Bumper Assembly 1 1-HR1004 1-HR1004 1-HR1004 1-HR1004 A1-HR1004 A1-HR1004 A1-HR1004-3 A1-HR1004-3
11 Spring Arbor 1 S400017 S400017 S400017 S400017 S400017 S400017 S400017 S400017
12 Latch Cam 1 S500019 S500019 S500019 S500019 S500019 S500019 S500019 S500019
14 Strain Relief 1 260697 260697 260697 260697 260697 260697 260697 260697
15 Flange Shaft 1 602348 602348 602348 602348 602348 602349 602391 602391
16 Split Lock Washer 3 902016 902016 902016 902016 902016 902016 902016 902016
17 Hex Bolt 1/4-20 3 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42 S2-42
18 Slip Ring and Brush 1 602296 602296 602296 602296 602296 602297 602375 602375
20 Snap Ring 1 S140-13 S140-13 S140-13 S140-13 S140-13 S140-13 None None
21 Wire Nut 3 260774 260774 260774 260774 260774 260774 ** **
22 Grounding Cord 1 600283 600283 600283 600283 600283 600283 None None
23 Lock Washer 1 S115-10 S115-10 S115-10 S115-10 S115-10 S115-10 S115-8 (x4) S115-8 (x4)
24 Quick Connect 1 260609 260609 260609 260609 260609 260609 None None
25 Terminal Block 1 600205 600205 600205 600205 600205 600205 None None
27 Screw 10-32 x 3/8” 6 300001 300001 300001 300001 300001 300001 300001 300001
28 Latch Plate Spring 1 S400018 S400018 S400018 S400018 S400018 S400018 S400018 S400018
30 Screw 10-32 x 1” 1 300035 300035 300035 300035 300035 300035 300035 300035
31 Latch Bumper 1 S400021 S400021 S400021 S400021 S400021 S400021 S400021 S400021
32 Latch Plate Assembly 1 S400109 S400109 S400109 S400109 S400109 S400109 S400109 S400109
33 Latch Bushing 1 S400012 S400012 S400012 S400012 S400012 S400012 S400012 S400012
35 Main Shaft 1 262244 262244 262244 262244 262244 262397 262462 262462
36 Spacing Washer 2 300034 300034 300034 300034 300034 300034 300034 300034
37 Drive Spring Assembly 1 S600050 S600050 S600050 S600050 S600050 S600050 S600050 S600050
38 Spring Case and Hub 1 S600094 S600094 S600094 S600094 S600094 S600094 S600094 S600094
39 Nut, Nyloc 1 S82-15 S82-15 S82-15 S82-15 S82-15 S82-15 S82-15 S82-15
40 Base Assembly 1 600029 600029 600029 600029 600029 600029 600029 600029
41 Disc, Sheave 1 260151 260151 260151 260151 260151 260151 260151 260151
42 Sheave Assembly 1 600281 600281 600281 600281 600281 600281 S602388 S602388
43 Gasket 1 260696 260696 260696 260696 260696 260696 None None
44 Cover 1 261723 261723 261723 261723 261723 261723 ** **
45 Plug 50’, RV Plug 35’ 1 None None None None None None 602409 None
46 Dual GFCI Receptacle 1 None 602332-50 602255-50 602255-50 None None None None
47 Single Outlet (Female) 1 602451-50 None None None None None None None
56 Grounding Terminal 1 None None None None None None 260674 260675
57 Flying Lead 1 None None None None 602353-50 602475-50 None 602418
Dimension Size Index # - See page 6 2 2 2 2 2 2 3 3
*Included in hardware kit #602048
**Included in hardware kit #602375
