Components and Specifications
G
ua
rd
ia
n
Fa
ll
Pr
ot
ec
tio
n
6
30
5
S.
2
31
st
S
t.
, K
en
t,
W
A
9
80
32
p
ho
ne
: (
80
0)
4
66
-6
38
5
f
ax
: (
80
0)
6
70
-7
89
2
w
w
w
.g
ua
rd
ia
nf
al
l.c
om
10
Connection points for PFAS
attachment, HLL Cable
attachment, or Pass-Through
Accessory attachment.
Base Assembly
Mounting Bolts
Hex Bolts
and Nuts
Clamp Assemblies
Post
Materials: Powder-coated steel, zinc-plated steel, and zinc.
HLL Cable (Product #:01400, sold separately): MUST be
3/8” galvanized aircraft cable. Necessary length will vary
depending on system. Cable must span entire length of
system, and include additional length necessary to
complete all connections and termination points.
3/8” Aircraft Cable
Part # Description
15048
15049
04730
04731
Stingray Absorbinator System for application under 60’. Includes (1) Absorbinator,
(3) Shackles, (2) Thimbles, (1) Turnbuckle, (6) Fist Grips, & (2) 2½” O-rings.
Stingray Absorbinator System for application over 60’. Includes (2) Absorbinators,
(4) Shackles, (2) Thimbles, (1) Turnbuckle, (6) Fist Grips, & (2) 2½” O-rings.
Stingray Post Assembly for steel beam. Includes (1) Post, (2) L Brackets, (2) Threaded Rods, (2) Wing Nuts,
& (1) Shackle. Standard base with 18” rod and standard flange hook. Does not include Pass-Through Top.
Stingray Pass-Through Top. Includes hardware.
Stingray 2 Post Kit. Includes (2) 04730 Post Assemblies, (1) 15049 HLL
Attachment Absorbinator System. For applications under 60’.
Stingray 3 Post Kit. Includes (3) 04730 Post Assemblies, (1) 04731 Pass-Through Top,
(1) 15049 HLL Attachment Absorbinator System. For applications over 60’.
04737
04736
Absorbinator
Pass-Through Top
