Poly-Tex Poly-Vent - Manual (Page 13)

13
INSTRUCTIONS:
4A. INSTALL END PANEL. MAKE SURE YOU
ARE USING THE CORRECT PANEL (LEFT
HAND OR RIGHT HAND).
4B. AFTER END PANEL IS PROPERLY FITTED
INTO POSITION, ALL HARDWARE HOLDING
FRONT, BACK, AND END PANELS MAY BE
TIGHTENED.
4C. INSTALL SIDE CLIPS AND 4-1/2" END CLIPS
OVER EDGES OF END PANEL, FRONT
PANEL, REAR PANEL, TOP AND BOTTOM
GUTTERS AS SHOWN BELOW.
1/4" x 3/4" HEX BOLT
1/4" LOCK WASHER
1/4" HEX NUT
4-1/2" END CLIP
(TOP AND BOTTOM)
SIDE CLIPS
END PANEL
#12 x 1" SELF
DRILLING SCREW
