TRAILER PARTS LIST HARDWARE
Part
No.
Part Description Qty.
1 Frame (deck) 1
2 Tongue (with wiring harness)
and Coupler (hitch)
1
3 Front Panel 1
4 Solid Ramp 1
5 Mesh Ramp 1
6 Side Panels 2
7 Wheel and Hub Assembly 2
8 Leaf-Spring 2
9 Axle 1
10 Fender 2
11 Tongue Side Brace 2
12 Wiring Harness 1
Make sure that all parts, as listed above, are included in your shipment. If any parts are
missing please contact NORTHSTAR at 1-855-375-3088.
Other tools needed for assembly: grease gun, flathead screwdriver, socket set, wrench set,
small zip-ties, small rubber mallet.
Part
No.
Description Qty.
A U-Bolt 4
B Spring Plates 2
C Large Locknuts 10
D 3 ½” threaded Pin-Bolt 5
E 3 5/8” threaded Pin-Bolts 2
F 8” Gate-Pin 2
G 3 ¾” Gate-Pin 2
H Large Nut 7
I Small Locknut 12
J Small Lock-Washer 24
K Flat-Washer 2
L Small Bolt 1” 24
M Cotter-Pin 7
N Spare Tire Lug Nut 2
O Taillight/Brake Light 2
P Running Light 2
Q Taillight/Brake Light L-Bracket 2
R License Plate Bracket 1
S Domed Panel Bolt 10
T
Small Brass Screw (included in
bag with blue wire connectors)
4
U Wire Connector 8
W Slotted Lock bolt 2
Y Tie Down Ring 8
Z Gate Lock With Chain 2
AA Dowel 2
