A-1 INSTALLATION
OUTBACK™ 185 (AU)
A-1
®i
TECHNICAL SPECIFICATIONS - OUTBACK™ 185 (AU) (K2706-3)
Make/Model Description Speed (RPM) Displacement Ignition Capacities
System
KOHLER 1 cylinder 3750RPM High Idle 429 cc Electric & Recoil Fuel: 25.7L
CH440 4 cycle 2250RPM Low Idle (26.2 cu. in.) Start; (6.8 gal.)
air-cooled 3400RPM Full Load
OHV petrol Bore x Stroke Manual Oil: 1.1 L.
14 HP @ Choke (1.2 Qts.)
3600 RPM 89 mm x 69 mm
Aluminum Block (3.50” x 2.70”)
w/ Cast Iron Sleeve
INPUT - PETROL ENGINE
RATED OUTPUT - WELDER
HEIGHT WIDTH DEPTH WEIGHT
651 mm 553 mm 800 mm 133.8 kg
25.62 in. 21.77 in. 31.48 in. 295.0 lbs.
-18° C TO 40° C (0° F TO 104° F) -40° C TO 55° C (-40° F TO 131° F)
OUTPUT -WELDER AND GENERATOR
OPERATING TEMPERATURE RANGE STORAGE TEMPERATURE RANGE
AMPS @ DC CONSTANT CURRENT DUTY CYCLE VOLTS @ RATED AMPERES
100 100% 25
130 60% 25
150 20% 25
185 MAX OUTPUT ---
Welding Ranges Welding Open Circuit Voltage AC Auxiliary Power
5700 Watts 240V 1PH
100% Duty Cycle
50 - 185 Amps DC 80 VDC Max. 5700 Peak Watts
5200 Continuous Watts
240 V 1PH
PHYSICAL DIMENSIONS
