C-2 ACCESSORIES C-2
K126-[ ] INNERSHIELD® PRO
GUN CONSUMABLE PARTS
LINER ASSEMBLY
*K613-X Gun Connector Kit is Required for 3/32” wire.
Wire Diameter
0.035
0.045
0.052
1/16
0.068
0.072
5/64
3/32*
Liner KP No.
KP44-3545-15
KP44-3545-15
KP44-116-15
KP44-116-15
KP44-564-15
KP44-564-15
KP44-564-15
KP45H-332-15*
INSULATED GUIDES/THREAD PROTECTOR
KP Number
KP2907-1
KP1987-1
KP1995-1
KP2090-1
Desired ESO
1.5" or less
1.50" to 2.00"
2.00" to 2.75"
2.75" or greater
KP Number
KP2908-1
Notes
Magnum Pro Tip Holder
CONTACT TIPS
Wire Diameter
0.035
0.045
0.052
1/16
0.068
0.072
5/64
3/32*
10-piece pack
KP2745-035R
KP2745-045R
KP2745-052R
KP2745-116R
KP2745-072R
KP2745-072R
KP2745-564R
KP2745-332R
100-piece pack
KP2745-035R-B100
KP2745-045R-B100
KP2745-052R-B100
KP2745-116R-B100
KP2745-072R-B100
KP2745-072R-B100
KP2745-564R-B100
KP2745-332R-B100
KP Numbers
GUN TUBES
Stainless Steel Jacketed
Classic Varnished Jacketing
TIP HOLDERS
KP Number
KP2906-62
KP2906-62R
KP2906-30R
KP2906-30R-L
KP2906-30
KP2906-30-L
Bend Angle
62°
62°
30°
30°
30°
30°
Notes
No reverse bend
With reverse bend
With reverse bend
With reverse bend, extended length
No reverse bend
No reverse bend, extended length
KP Number
KP2927-62R
KP2927-30R-L
KP3267-1
Bend Angle
62°
30°
30°
Notes
No reverse bend
With reverse bend
No reverse bend
