SAFETY PRECAUTION
WELDING VOLTAGE
Wire feed parts are electrically live while welding and
while feeding wire (with Touch Sense feature select-
ed). The electrically live parts are listed below:
Electrode Electrode Reel
Wire Drive Motor Drive Rolls
Gear Box Cross-seam Adjuster
Wire Straightener Welding Nozzle
Welding Cables Welding Cable Terminal
ELECTRIC SHOCK can kill.
• Only a qualified electrician should
connect the AutoDrive ® 19
Tandem. Installation should be
made in accordance with the
appropriate National Electrical
Code, the local codes and the infor-
mation in this manual.
• Turn off the input power to the
power source at the disconnect
switch or fuse box before working
on this equipment. Turn off the
input power to any other equipment
connected to the welding system at
the disconnect switch or fuse box
before working on this equipment.
• Do not touch electrically hot parts.
----------------------------------------------------------------------------------------
WARNING
A-1 INSTALLATION
AutoDrive ® 19 Tandem
A-1
TECHNICAL SPECIFICATIONS: AutoDrive ® 19 Tandem
INPUT VOLTAGE & CURRENT PHYSICAL SIZE TEMPERATURE RATING
Dimensions
Model Voltage* Input Amps* Height Width Depth Weight Operating Storage
K3171-1 40VDC 1.0 8.8 in. 10.38 in 3.12 in. 7 Lbs 14°F to 104°F -40°F to 185°F
(224 mm) (264 mm) (80 mm) (3.2 Kg.) (-10°C to 40°C) (-40°C to 85°C)
* When not driving a motor.
• Do not touch electrically live parts or
electrodes with your skin or wet cloth-
ing.
• Insulate yourself from the work and
ground.
• Always wear dry insulating gloves.
MECHANICAL HAZARDS
• Welding fixture or wire feeder will
move during welding or inching.
Keep away from pinch points.
• Electrode reel and drive rolls turn
during welding or inching. Keep
gloved hands away from areas that
may catch the glove.
------------------------------------------------------------------------------------------
CAUTION
