AIR VANTAGE ® 500(AU) KUBOTA
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS - AIR VANTAGE ® 500(AU) KUBOTA (K3212-1 )
Make/Model Description Speed (RPM) Displacement Starting Capacities
cu. in. (ltrs.) System
4 cylinder High Idle 1850 220.9(3.62) 12VDC Battery & Fuel: 25 gal.
KUBOTA 58 HP (43.2kw) starter (94.6 L)
V3600-T 1850 RPM Full Load 1850 Bore x Stroke inch (mm) Oil: 3.5gal. (13.2L)
Diesel Engine
Low Idle 1425 3.86 X 4.72 Radiator Coolant:
(98 x 120mm) 2.6gal. (9.8L)
INPUT - DIESEL ENGINE
RATED OUTPUT @ 104°F(40°C) - WELDER
Duty Cycle Welding Output Volts at Rated Amps
100% 500 Amps (DC multi-purpose) 40 Volts
60% 550 Amps (DC multi-purpose) 36 volts
50% 575 Amps (DC multi-purpose) 35 volts
PHYSICAL DIMENSIONS
Height (2) Width Depth Weight
42.0 in 32.7 in. 63.1 in. 1730 lbs.
(1066.8 mm) (830.1mm) (1603mm) (785kg)
(Approx)
1. Output rating in watts is equivalent to volt-amperes at unity power factor.
Output voltage is within +/- 10% at all loads up to rated capacity. When welding, available auxiliary power will be reduced.
2. Top of Enclosure, add 7.0” (177.8mm) for exhaust pipe.
OUTPUT @ 104°F(40°C) - WELDER AND GENERATOR
Welding Range
30 - 575 Amps CC/CV
20 - 250 Amps TIG
Open Circuit Voltage
60 Max OCV @ 1850 RPM
Auxiliary Power (1)
2 x 240 VAC Receptacles
2 x 3600 WATTS, 60 Hz., Single Phase
Compressor Model Description Delivery Maximum System Compressor Capacities
Pressure Profection
VMAC™ Direct-Drive Rotary High Idle Mode: 150 PSI Safety Relief Valve 1.3 gal.(5.0 ltrs)
S700066 Screw Air Compressor 60 CFM @ 100PSI (10.5 kg/cm 2 ) 200 PSI
(28.3 Ltr/sec. @ (10.5 kg/cm 2 )
7.0 kg/cm)
Low Idle Mode: High Temperature
40 CFM @ 100PSI Automatic Shutdown
(18.9 Ltr/sec. @ 290° F (143°C)
7.0 kg/cm)
COMPRESSOR SPECIFICATIONS
