Pipe Thawing with an arc welder can cause fire,
explosion, damage to electric wiring or to the arc
welder if done improperly. The use of an arc
welder for pipe thawing is not approved by the
CSA, nor is it recommended or supported by
Lincoln Electric.
------------------------------------------------------------------------
K2354-1 Air Dryer Kit - Minimizes water content in
supply air. Avoids cold weather air hose ice up.
K2356-1 Control Panel Cover Kit - Clear plexiglass
cover to protect control panel from dirt and debris, and
to visually monitor machine operation. Lockable to
deter vandalism.
K2340-1 Lockable Fuel Cap / Flash Arrester Kit -
For use in locations where flash arrester safety is
required. Lockable fuel cap prevents tampering with
fuel. Green cap color provides a visual reminder to
use diesel when refueling.
K2359-1 Cold Weather Heater and Tarp Kit - For
extreme cold conditions where normal engine starting
is not sufficient. Includes oil pan heater, engine water
heater and radiator grill tarp.
TIG OPTIONS
K870 Foot Amptrol ® - Varies current while welding
for making critical TIG welds and crater filling.
Depress pedal to increase current. Depressing pedal
fully achieves maximum set current. Fully raising the
pedal finishes the weld and starts the afterflow cycle
on systems so equipped. Includes 25 ft. (7.6m) control
cable.
K963-3 Hand Amptrol ® - Varies current for making
critical TIG welds. Fastens to the torch for convenient
thumb control. Comes with a 25 ft. (7.6m) cable. (for
larger handle 18 or 26 series torches)
C-1 ACCESSORIES C-1
AIR VANTAGE ® 500 CUMMINS
OPTIONAL FIELD INSTALLED
ACCESSORIES
K802N POWER PLUG KIT - Provides four 120V
plugs rated at 20 amps each and one dual voltage,
full KVA plug rated at 120/240V, 50 amps. 120V plug
may not be compatible with NEMA common house-
hold receptacles.
K802-R POWER PLUG KIT - Provides four 120V
plugs rated 15 amps each and one dual voltage, full
KVA plug rated at 120/240V, 50 amps, 120V plug is
compatible with NEMA common household recepta-
cles.
K857 25 ft. (7.5 m) or K857-1 100 ft. (30.4 m)
REMOTE CONTROL - Portable control provides
same dial range as the output control on the welder
from a location up to the specified length from the
welder. Has convenient plug for easy connection to
the welder. The AIR VANTAGE
® 500 CUMMINSis
equipped with a 6-pin connector for connecting the
remote control.
K704 ACCESSORY SET - Includes 35 feet (10 m) of
electrode cable and 30 feet (9 m) of work cable, head-
shield, filter plate, work clamp and electrode holder.
Cable is rated at 500 amps, 60% duty cycle.
K2641-2 FOUR WHEELED STEERABLE YARD
TRAILER
For in plant and yard towing. Comes standard with a
Duo-Hitch™, a 2” Ball and Lunette Eye combination
Hitch.
K2636-1 TRAILER - Two-wheeled trailer with optional
fender and light package. For highway use, consult
applicable federal, state, and local laws regarding
possible additional requirements. Comes standard
with a Duo-Hitch™, a 2” Ball and Lunette Eye combi-
nation hitch. A fender & a light package. Order:
K2636-1 Trailer
K2639-1 Fender & Light Kit
K2640-1 Cable Storage Rack
K887-1 ETHER START KIT - Provides maximum cold
weather starting assistance for frequent starting below
10°(-12°C). Required Ether tank is not provided with
kit.
K1847-1 SPARK ARRESTOR KIT - Easily mounts to
standard muffler.
WARNING
