A-1 INSTALLATION
SQUARE WAVE™ TIG 175
A-1
TECHNICAL SPECIFICATIONS - SQUARE WAVE™ TIG 175 (K1478-5)
Wiring and Protection based on the 2008 National Electric Code.
Use a Super Lag type Fuse or Circuit Breaker with a delay in tripping action. Models with NEMA 6-50P plug
may be used with a 50 amp protected 6-50R receptacle, or with a maximum 70 amp protected 6-50R receptacle
if dedicated for the welder.
Code
Number
11691
11826
Volts at Rated Amperes
15.0 V AC/DC
14.7 V AC/DC
14.3 V AC/DC
14.1V AC/DC
26.0 V AC/DC
25.0 V AC/DC
25.0 V AC/DC
24.0 V AC/DC
Type of Output
CC (Constant Current)
AC/DC
Input Current at
Rated Output
58/52 AC/DC Stick & DC TIG - 64/57 AC TIG
Amps
150
125
110
90
150
125
110
90
Maximum Open
Circuit Voltage
(STICK AND TIG)
AC OCV: 74
DC OCV: 59
Standard
Voltage
208/230/1/60
Duty Cycle
GTAW 25% Duty Cycle
40% Duty Cycle
60% Duty Cycle
100% Duty Cycle
SMAW 25% Duty Cycle
40% Duty Cycle
60% Duty Cycle
100% Duty Cycle
Output Current
Range
10-175 Amps
AC and DC
INPUT - SINGLE PHASE ONLY
RATED OUTPUT
OUTPUT
RECOMMENDED FUSE SIZES
Height Width Depth Weight
Power 19.53 in. 13.72 in. 24.94 in. Approx. 200 lbs.
Source 496 mm 349 mm 633 mm 90.9 kgs.
PHYSICAL DIMENSIONS
