Page 30

AFL2-17A/AB-H61

P a g e 10

 2 x USB 2.0 connectors

 2 x USB 3.0 connectors

 1 x VGA port

Figure 1-8: AFL2-17A/AB-H61 Bottom Panel

1.2.4 Le ft S id e P a n e l

The left side panel of the AFL2-17A/AB-H61 has the following features (Figure 1-9):

 2 x Audio jacks (Line out, MIC)

 1 x RJ-45 LAN connector

 1 x USB 2.0 connector
