REPLACING THE BATTERY AND MASTER RESET
When the display starts to dim or goes blank, it is time to
replace the battery.
If the display is not uniformly dim or blank, and appears to
display “erroneous data”, do a Master Reset by pressing all
3 buttons simultaneously for 3 seconds and then release.
The display should go blank, then turn all segments on, then
display 0 steps in Step Mode.
Note: All the settings will return to their default setting values.
If you need to change the battery, the settings will also revert
to default settings.
Battery
To replace the battery:
1. Insert a coin into the slot on the
bottom of the case, and twist to
loosen the faceplate. Remove
faceplate and set aside.
2. Locate the battery holder as seen
on sketch. Pull out the old battery,
and push a new LR-44 battery into the holder,
with positive terminal (+) facing up.
3. Snap faceplate back into place, hooking the bottom
two tabs first, then closing by pressing together at the
top two tabs.
SPECIFICATIONS, FEATURES, and FUNCTIONS
Description of Functions
• Counts Steps up to 99,999 then rollover.
• Counts Time spent in step activity, up to 999 Min 59 sec,
then rollover. Automatically counts whenever step activity
is occurring.
• Counts distance traveled during step activity, up to
999.99 mi or km, then rollover. Automatically counts
whenever step activity is occurring.
• Adjustable stride length for greater distance accuracy
(default setting is 21 in/53 cm, but can be set from 12-72 in
(30-180 cm), in 0.25 in / 1 cm increments.
• 12 Hour Clock (default setting is 10.00am).
• Adjustable Step Filter (default setting is 1 step, but can
be set from 0-5 steps) to increase step count accuracy.
• Switchable between English and Metric units, without
losing data (default setting is English units).
REGISTER NOW Please return
your AE180XL Registration to
the Repair Center address in the
warranty, and we will let you know
about future products.
Email (preferred)
User
NO-PROOF-OF-PURCHASE LIMITED WARRANTY
Free service for first year of ownership;
$12 fee for service thereafter. See label inside unit for date.
See www.ACCUSPLIT.com/support for details
Battery, replacing . . . . 25-26
Clock, setting . . . . . . . . 13-14
Current day’s results,
viewing . . . . . . . . . . . . . .20
Setting Mode, exiting . . . .14
Open your pedometer . . . .4
Safety Leash . . . . . . . . 18-19
Setting up pedometer. . 5-12
Step Filter Setting,
change . . . . . . . . . . . 21-22
Stride Length,
setting . . . . . . . . . . . . 10-12
Unit of measure,
changing. . . . . . . . . . . . .23
Wearing pedometer . . . . .15
Warranty . . . . . . . . . . . . . .29
INDEX
