Accusplit AE1120M2 - Manual

WEARING YOUR PEDOMETER
While gently holding the belt clip open, slide the pedometer
onto your belt or the top edge of your pants or skirt. It should
fit snugly and level, above one knee.
Note: The pedometer should be as vertical as possible.
Walkers with larger stomachs may find it helpful to wear the
pedometer farther back on the body, toward one hip.
To avoid losing or dropping your pedometer, use the included
leash and clip to fasten the pedometer securely to your
clothing.
Attaching the Leash:
Attach the pedometer to the leash by
looping the leash around the pedometer belt clip. Next, clasp
the waistband of your clothing with the attached clip. You can
also use a safety pin to fasten the leash to your clothing, loop
the leash through your belt or belt loop, or use a badge holder.
VIEWING YOUR RESULTS
Once you put on your pedometer, it will automatically begin
to record your steps. Press the DAY button to view today’s
step count. Press the TOTAL button to view total steps taken.
MEMORY PEDOMETER
OPERATING INSTRUCTIONS
ACCUSPLIT, Inc. • 2290M Ringwood Ave. • San Jose, CA 95131
800-965-2008 • 925-226-0888 • FAX 925-463-0147 • www.ACCUSPLIT.com • [email protected]
ACCUSPLIT®
EAGLE
™
1120M2
Eat Right! Walk More! Live Well!
The ACCUSPLIT Lifestyle
Congratulations on taking the first step to wellness with your purchase of an ACCUSPLIT
pedometer. It’s easy to set up your new pedometer. Just follow the steps below, and start walking!
RESETTING YOUR PEDOMETER
Most people prefer to reset step counts daily.
To reset: While displaying Day’s Steps, press and hold DAY
button for at least three seconds to reset to zero. When
displaying Total Steps, press TOTAL button for three seconds
to reset Total and Day’s Steps to zero.
AUTO MOVEMENT SENSOR
1. To filter out random movements, the unit remains in standby
mode until 5 continuous steps are registered. Only then are
the 5 steps calculated in, and an Active indicator “▲” appears
on the upper left of display.
2. When regular walk/run movement stops, after 2 seconds the
timer pauses and the unit switches to standby status (Active
indicator “▲” disappears).
REPLACING THE BATTERY
When the display starts to dim or goes blank, it is time to replace
the battery. Your pedometer uses one Type L1142 (LR43) 1.5
volt silver oxide battery. To replace:
1. Using a jeweler’s screwdriver, loosen small screw on back of
unit. Remove back of case.
2. Slide the old battery gently out of its holder. Replace it with a
new battery. The battery’s positive (+) terminal should be
FACE UP while you put it into the pedometer.
3. Gently press front and back of pedometer case back together,
being sure to line up slots and tabs at top and bottom of unit.
ACCUSPLIT
EAGLE
1 1 2 0 M 2
T W 1 5 M G
T
O
T
A
L
D
A
Y
AccuSTEP 10000.org
ST
TL
MODES
• “D”– “Day’s Steps”
Counts steps taken since last RESET.
• “T”–”Total Steps”
Keeps track of all steps taken, even after
Day’s Steps are reset.
DAY button TOTAL button
970-043
First, loop the
pedometer clip
Next, loop the metal
clip, then clasp clothing
Or, loop a
badge holder, then
put into pocket
(Badge holder
not included)
Or, loop a belt
or belt loop
REGISTER NOW Please return
your AE1120M2 Registration to
the Repair Center address in the
warranty, and we will let you
know about future products.
Email (preferred)
User
